MSI B760M GAMING PLUS WIFI GEN5
Original price was: ₹18,799.00.₹17,449.00Current price is: ₹17,449.00.
- ✅ Supports Intel 12th / 13th / 14th Gen processors (LGA 1700)
- ✅ DDR5 memory up to 256GB (up to 7200+ MT/s OC)
- ✅ PCIe 5.0 x16 slot for next-gen GPUs
- ✅ Built-in Wi-Fi 6E + Bluetooth 5.3
- ✅ 2.5G LAN for fast wired networking
- ✅ Dual M.2 slots with Gen4 NVMe support
- ✅ 12+1+1 power phase design for stable performance
- ✅ Extended heatsinks + M.2 Shield Frozr cooling
- ✅ USB 10Gbps Type-C and multiple USB ports
- ✅ Micro-ATX form factor for compact builds
MSI B760M GAMING PLUS WIFI GEN5
MSI B760M GAMING PLUS WIFI GEN5
The MSI B760M GAMING PLUS WIFI GEN5 is a feature-rich Micro-ATX motherboard built for gamers and enthusiasts using Intel’s 12th, 13th, and 14th Gen processors. Powered by the Intel B760 chipset, it delivers strong performance with DDR5 memory support, PCIe 5.0 graphics capability, and modern connectivity including Wi-Fi 6E and 2.5G LAN.
Key Features
🧠 Intel LGA 1700 Platform
- Compatible with Intel Core 12th, 13th, and 14th Gen processors, offering strong performance for gaming and multitasking.
💾 High-Speed DDR5 Memory
- Supports up to 256GB DDR5 RAM with speeds up to 7200+ MT/s (OC)
- Includes Memory Boost & XMP support for optimized performance.
🎮 PCIe 5.0 Graphics Support
- Features a PCIe 5.0 x16 slot, delivering maximum bandwidth for next-gen GPUs and expansion cards.
⚡ Fast Storage & Expansion
- Equipped with Lightning Gen4 M.2 slots for high-speed NVMe SSDs
- Includes M.2 Shield Frozr to maintain SSD performance under load.
🌐 Advanced Networking
- Wi-Fi 6E + Bluetooth 5.3 for fast and low-latency wireless connectivity
- 2.5G LAN ensures stable, high-speed wired networking.
🔋 Strong Power Delivery
- 12+1+1 Duet Rail Power System with Core Boost ensures stable CPU performance under heavy workloads and gaming sessions.
❄️ Premium Thermal Design
- Extended heatsinks with 7W/mK thermal pads
- Designed to keep VRMs and components cool during long gaming sessions.
⚙️ DIY-Friendly Features
- Reinforced PCIe slot (Steel Armor)
- Easy installation features and clean layout for hassle-free builds.
🔊 Audio Boost
- High-quality onboard audio with isolated circuitry for immersive gaming sound.
SPECIFICATIONS
| CPU | Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors LGA 1700
|
|---|---|
| Memory | 4x DDR5, Maximum Memory Capacity 256GB Memory Support DDR5 7200 – 5600 (OC) MT/s / 5600 – 4800 (JEDEC) MT/s Max. overclocking frequency: • 1DPC 1R Max speed up to 7200+ MT/s • 1DPC 2R Max speed up to 6600+ MT/s • 2DPC 1R Max speed up to 6400+ MT/s • 2DPC 2R Max speed up to 5600+ MT/s Supports Intel® XMP 3.0 OC
|
| Onboard Graphics | 2x HDMI™ Support HDMI™ 2.1, maximum resolution of 4K 60Hz* 2x DisplayPort Support DP 1.4, maximum resolution of 4K 60Hz* |
| Slot | 2x PCI-E x16 slot (Qty) 1x PCI-E x1 slot (Qty) PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
|
| Audio | Realtek® ALC897 Codec 7.1-Channel High Definition Audio
|
| Storage | 2x M.2 (Qty) M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G (Qty) |
