AMD EPYC 9755
The AMD EPYC™ 9755 stands as the pinnacle of the standard performance line. Unlike the “dense” models, this processor uses full-fat Zen 5 cores, packing 128 Cores and a massive 512MB L3 Cache into the socket. It is designed for the most demanding enterprise workloads, including in-memory databases, heavy simulation (CFD), and AI model training. With a boost clock of 4.1 GHz and support for AVX-512, the 9755 delivers “no-compromise” performance, offering the core count of a dense chip with the per-core speed and cache depth of a performance chip.
Product Details
| General Information | |
|---|---|
| Processor Model | AMD EPYC 9755 |
| Market Segment | Server / Workstation |
| Architecture | Zen 5 (Turin) |
| Codename | Turin |
| Generation | EPYC (Zen 5) |
| Production Status | Active |
| Launch Date | October 10, 2024 |
| Part Number | 100-000001443 |
| Performance Specifications | |
|---|---|
| CPU Cores | 128 |
| Threads | 256 |
| Base Clock | 2.7 GHz |
| Max Boost Clock | Up to 4.1 GHz |
| Reference Clock | 100 MHz |
| Multiplier | 27.0x |
| Unlocked Multiplier | No |
| TDP | 500 W |
| Configurable TDP | 450 W – 500 W |
| SMP Support | Up to 2 CPUs |
| Memory Specifications | |
|---|---|
| Memory Type | DDR5 |
| Maximum Memory Speed | 6000 MT/s |
| 2DPC Rated Speed | 4400 MT/s |
| Memory Channels | 12-Channel |
| Memory Bandwidth | 576 GB/s |
| ECC Memory Support | Yes |
| Cache Configuration | |
|---|---|
| L1 Cache | 80 KB per Core |
| L2 Cache | 1 MB per Core |
| L3 Cache | 512 MB Shared |
| Platform & I/O | |
|---|---|
| Socket | AMD Socket SP5 |
| Package | FC-LGA6096 |
| PCI Express Support | PCIe Gen 5 |
| PCIe Lanes | 128 |
| CXL Support | CXL 2.0 |
| Integrated Graphics | Not Available |
| Manufacturing Details | |
|---|---|
| Foundry | TSMC |
| CPU Process Node | 4 nm |
| I/O Die Process | 6 nm |
| Transistor Count | 133.04 Billion |
| Die Configuration | 16 × 70.6 mm² |
| Virtualization & Enterprise Features | |
|---|---|
| AMD-V Virtualization | Yes |
| SMT (Simultaneous Multithreading) | Yes |
| Precision Boost 2 | Yes |
| SEV-SNP | Yes |
| 5-Level NPT | Yes |
| AVIC | Yes |
| IOMMU | Yes |
| Supported Instruction Sets | |
|---|---|
| SIMD Extensions | MMX, SSE, SSE2, SSE3, SSSE3, SSE4A, SSE4.1, SSE4.2 |
| Advanced Vector Extensions | AVX, AVX2, AVX-512 |
| AI Instructions | AVX-VNNI, VNNI/VEX, BFloat16 |
| Other Features | AES, SHA, F16C, FMA3, BMI1, BMI2, AMD64, EVP |
| Security Features | SMAP, SMEP, IBRS |
| Key Highlights | |
|---|---|
| Core / Thread Count | 128 Cores / 256 Threads |
| Maximum Cache | 512 MB L3 Cache |
| Maximum Memory Support | 12-Channel DDR5 @ 6000 MT/s |
| Expansion | 128 PCIe Gen 5 Lanes |
| Virtualization | Enterprise-Grade AMD-V & SEV-SNP |
| Best Suited For | AI Servers, HPC, Virtualization, Cloud Infrastructure, Enterprise Workloads |
