Gigabyte GP-P550SS Silver
Original price was: ₹5,833.00.₹3,469.00Current price is: ₹3,469.00.
- Power Output: 550W
- Efficiency: 80 PLUS Silver (~90% at 50% load)
- Form Factor: ATX 12V v3.0 (compatible with v3.1)
- Fan: 120mm FDB
- Input Voltage: 155–240V
- Cable Type: Non-modular, flat cables
- MTBF: >100,000 hours
Gigabyte GP-P550SS Silver
Power Supply
Gigabyte GP-P550SS Silver
The Gigabyte GP-P550SS is a high-efficiency 550W power supply unit designed to deliver stable and reliable performance for modern desktop systems. Built with the latest ATX 3.0 standard, it ensures compatibility with newer hardware while maintaining efficient power delivery and system safety.
Key Features
- 80 PLUS Silver certified (230V EU)
- Support Intel ATX 3.0 standard (compatible with ATX 3.1)
- 120mm Fluid Dynamic Bearing (FDB) Fan
- Flat cable design
- Powerful single +12V rail
- OVP/OPP/SCP/UVP/OCP/OTP protection
- 3 years warranty (Adjusted according to different regions)
120MM FLUID DYNAMIC
BEARING(FDB) FAN
High-performance Fluid Dynamic Bearing fan uses oil film shock absorption technology to effectively reduce noise, making it quieter than conventional sleeve fan and providing more than twice the lifespan. In addition, the fan will detect the current power usage and temperature, automatically adjust the fan speed to minimize the noise.
SPECIFICATIONS
Model
GP-P550SS
Type
Intel Form Factor ATX 12V v3.0 (compatible with ATX 3.1)
PFC
Active PFC (>0.9 typical)
Input Voltage
155-240 Vac
Input Current
6.3A
Input Frequency
50-60 Hz
Output Capacity
550W
Dimensions
150 x 140 x 86 mm
Fan Type
120mm Fluid Dynamic Bearing (FDB) fan
80 PLUS
Silver
Efficiency
90% at typical load (230V EU)
MTBF
>100,000 hours
Protections
OVP/OPP/SCP/UVP/OCP/OTP
Power Good Signal
100-150ms
Hold Up Time
>16ms
Cable Type
Flat, All black
Connectors
ATX/MB 20+4 Pin x 1 : 600mm*1
CPU/EPS 4+4 Pin x 1 : 650mm*1
PCI-e 6+2 Pin x 2 : 600mm+120mm*1
SATA x 3 + 4 Pin Peripheral x 1 : 500mm+120mm+120mm+120mm*1
SATA x 2 + 4 Pin Peripheral x 2 : 500mm+120mm+120mm+120mm*1
CPU/EPS 4+4 Pin x 1 : 650mm*1
PCI-e 6+2 Pin x 2 : 600mm+120mm*1
SATA x 3 + 4 Pin Peripheral x 1 : 500mm+120mm+120mm+120mm*1
SATA x 2 + 4 Pin Peripheral x 2 : 500mm+120mm+120mm+120mm*1
