Gigabyte GP-UD1300GM PG5
Original price was: ₹22,569.00.₹20,909.00Current price is: ₹20,909.00.
- Rated Power: 1300 W
- Certification: 80 PLUS Gold (~90 % efficiency)
- Form Factor: ATX 12V v3.1 (Intel ATX 3.0 compliant)
- Cooling: 140 mm double ball bearing fan
- PCIe Connector: Native PCIe Gen 5 (12VHPWR)
- Protections: OVP, OPP, SCP, UVP, OCP, OTP
- Modular Cabling: Fully modular flat black cables
- MTBF: >100,000 hours
- Dimensions: 150 × 160 × 86 mm
Available on backorder
Gigabyte GP-UD1300GM PG5
Gigabyte GP-UD1300GM PG5
Power Supply
The Gigabyte GP‑UD1300GM PG5 is a high‑capacity 1300 W power supply designed for enthusiast gaming PCs, workstations, and high‑power rigs. Built with Intel ATX 3.0/3.1 compliance and PCIe Gen 5 support, this PSU delivers stable, efficient power and future‑ready compatibility for modern hardware.
Key Features
- Ultra Durable
- Main Japanese capacitors
- Enhanced thermal solution
- 140mm double ball bearing fan
- OVP/OPP/SCP/UVP/OCP/OTP protection
- Support PCIe Gen 5.0 graphics card
- Support Intel ATX 3.0 standard
- 80 PLUS Gold certified
- Fully modular design
- Compact size
- 10 years warranty (Adjusted according to different regions)
Support PCIe Gen 5.0 graphics card
The UD1300GM PCIE 5.0 can sustain up to 3x GPU power excursion. It has a 16-pin connector and comes with a high-quality native 16-pin cable that allows you to use the PSU with a PCIe Gen 5.0 graphics card. This cable can support up to 600 watts of power to the graphics card.
SPECIFICATIONS
Model
GP-UD1300GM PG5
Type
Intel Form Factor ATX 12V v3.0
PFC
Active PFC (>0.9 typical)
Input Voltage
100-240 Vac (full range)
Input Current
15-6.5A
Input Frequency
60-50 Hz
Output Capacity
1300W
Dimensions
150 x 160 x 86 mm
Fan Type
140mm double ball bearing fan
80 PLUS
Gold
Efficiency
90% at typical load
MTBF
>100,000 hours
Protections
OVP/OPP/SCP/UVP/OCP/OTP
Power Good Signal
100-150ms
Hold Up Time
>16ms
Cable Type
Flat, All black
Connectors
ATX/MB 20+4 Pin x 1 : 610mm*1
CPU/EPS 4+4 Pin x 2 : 650mm*2
PCIe 16 Pin x 1: 700mm*1
PCIe 6+2 Pin x 8 : 650mm+150mm*3, 650mm*2
SATA x 12 : 650mm+150mm+150mm+150mm*3
4 Pin Peripheral x 6+4-Pin floppy x 2 : 600mm+150mm+150mm+150mm*2
CPU/EPS 4+4 Pin x 2 : 650mm*2
PCIe 16 Pin x 1: 700mm*1
PCIe 6+2 Pin x 8 : 650mm+150mm*3, 650mm*2
SATA x 12 : 650mm+150mm+150mm+150mm*3
4 Pin Peripheral x 6+4-Pin floppy x 2 : 600mm+150mm+150mm+150mm*2
