Gigabyte GP-UD750GM Gold
Original price was: ₹9,199.00.₹7,479.00Current price is: ₹7,479.00.
- Power Output: 750W
- Efficiency: 80 PLUS Gold (~90% at 50% load)
- Form Factor: ATX (ATX 3.0 on PG5 variants)
- Fan: 120mm Hydraulic Bearing Fan
- Input Voltage: 100–240V (full range)
- Cable Type: Fully modular, flat black cables
- MTBF: >100,000 hours
- Dimensions: 150 × 140 × 86 mm
Available on backorder
Gigabyte GP-UD750GM Gold
Gigabyte GP-UD750GM Gold
Power Supply
The Gigabyte GP-UD750GM is a modern 750W power supply built under Gigabyte’s Ultra Durable series, offering high efficiency, fully modular flexibility, and next-gen compatibility. Designed for gaming and high-performance PCs, it combines reliable components with support for the latest hardware standards.
Key Features
- Ultra Durable
- Main Japanese capacitors
- Enhanced thermal solution
- 120mm smart hydraulic bearing (HYB) fan
- OVP/OPP/SCP/UVP/OCP/OTP protection
- 80 PLUS Gold certified
- Fully modular design
- Powerful single +12V rail
- Compact design
- 5 years warranty (Adjusted according to different regions)
HIGH QUALITY
JAPANESE CAPACITORS
The main capacitors use high quality Japanese capacitors to produce the efficient performance and ensure the longer reliability.
ENHANCED THERMAL
SOLUTION
Compared with the standard thermal solution, we have enlarged the heatsink by about 200% or more, and optimized the airflow. The heat dissipation performance is increased by more than 10%, thus prolonging the service life of the components.
SPECIFICATIONS
Model
GP-UD750GM
Type
Intel Form Factor ATX 12V v2.31
PFC
Active PFC (>0.9 typical)
Input Voltage
100-240 Vac (full range)
Input Current
12-6A
Input Frequency
60-50 Hz
Output Capacity
750W
Dimensions
150 x 140 x 86 mm
Fan Type
120mm Hydraulic Bearing(HYB)fan
80 PLUS
Gold
Efficiency
90% at typical load
MTBF
>100,000 hours
Protections
OVP/OPP/SCP/UVP/OCP/OTP
Power Good Signal
100-150ms
Hold Up Time
>16ms
Cable Type
Flat, All black
Connectors
ATX/MB 20+4 Pin x 1 : 610mm*1
CPU/EPS 4+4 Pin x 2 : 600mm*2
PCI-e 6+2 Pin x 4 : 600mm+150mm*2
SATA x 8 :
600mm+150mm+150mm+150mm*2
4 Pin Peripheral x 3+4-Pin floppy x 1 : 500mm+120mm+120mm+150mm*1
CPU/EPS 4+4 Pin x 2 : 600mm*2
PCI-e 6+2 Pin x 4 : 600mm+150mm*2
SATA x 8 :
600mm+150mm+150mm+150mm*2
4 Pin Peripheral x 3+4-Pin floppy x 1 : 500mm+120mm+120mm+150mm*1
