MSI IPC W880 ATX DDR5 Industrial Motherboard

Features

• Industrial ATX motherboard – Designed for industrial PCs, automation, machine vision and edge computing.
• Intel W880 chipset – Professional platform for Intel Arrow Lake-S processors.
• LGA1851 socket – Supports Intel Core Ultra 9/7/5 processors up to 125W.
• 4 DDR5 RAM slots – Supports ECC and Non-ECC UDIMM memory up to 256GB.
• DDR5-5600 support – High-speed memory for demanding applications.
• 2 × 2.5GbE LAN – SKU2 has 2 Intel I226-LM 2.5Gbps LAN ports.
• Triple-display support – VGA + HDMI + DisplayPort can run 3 independent displays.
• 2 × M.2 slots – Supports high-speed NVMe SSD storage.
• 4 × SATA 3.0 – Additional storage support with RAID 0/1/5/10.
• PCIe Gen 5 expansion – Supports high-speed expansion cards.
• Multiple COM ports – 6 COM ports for industrial equipment and serial devices.
• Many USB ports – 8 × USB 3.2 Gen 2, 2 × USB 3.2 Gen 1 and 3 × USB 2.0.
• TPM 2.0 – Provides hardware-based security.
• ATX size – 305 × 244mm standard ATX form factor.

Specifications
