MSI MAG B860 TOMAHAWK WIFI
Original price was: ₹26,499.00.₹23,799.00Current price is: ₹23,799.00.
- ✅ ATX form factor – ideal for full-size gaming builds
- ✅ Strong all-round performance with PCIe 5.0 + DDR5
- ✅ Excellent connectivity: Wi-Fi 7, 5GbE LAN, Thunderbolt 4
- ✅ Flexible storage with triple M.2 slots
- ✅ Reliable VRM for high-end CPUs (though not extreme overclocking)
- ✅ Great value alternative to expensive Z890 motherboards
MSI MAG B860 TOMAHAWK WIFI
MSI MAG B860 TOMAHAWK WIFI
The MSI MAG B860 TOMAHAWK WIFI is a premium mid-range ATX motherboard designed for Intel’s latest Core Ultra processors (LGA 1851). Part of MSI’s MAG (MSI Arsenal Gaming) series, it balances performance, durability, and connectivity, making it an excellent choice for gamers and power users who want near-flagship features without the cost of a Z890 board. With robust VRM design, PCIe 5.0 support, Wi-Fi 7, and extensive storage options, it delivers a well-rounded platform for modern high-performance PCs.
Key Features
⚡ Performance & Power Delivery
- Supports Intel Core Ultra (Series 2) processors – LGA 1851
- 12+ phase VRM design (approx. 720A) for stable performance under heavy loads
- DDR5 memory support up to ~9200+ MT/s (OC)
- Optimized for sustained workloads and multitasking
🚀 Expansion & Storage
- PCIe 5.0 x16 slot for next-gen GPUs
- 3× M.2 slots (1× PCIe 5.0 + 2× PCIe 4.0)
- Supports SATA and NVMe drives for flexible storage configurations
🌐 Connectivity
- Wi-Fi 7 (Intel Killer BE1750x) for ultra-fast wireless speeds (~5.8 Gbps)
- 5G LAN (Killer E5000) for low-latency wired networking
- Thunderbolt 4 / USB4 support (40Gbps)
- Multiple high-speed USB ports including USB 10Gbps Type-C
❄️ Cooling & Build Quality
- Large extended VRM heatsinks with efficient thermal design
- M.2 Shield Frozr heatsinks for SSD cooling
- 6-layer PCB for durability and signal stability
- Multiple fan headers with smart control
🛠️ DIY & User-Friendly Features
- EZ Debug LEDs for troubleshooting
- Tool-less EZ M.2 installation clips
- Pre-installed I/O shield
- Clean, stealthy black military-style design
SPECIFICATIONS
| Chipset | INTEL B860 |
|---|---|
| CPU | Supports Intel® Core™ Ultra Processors (Series 2) LGA 1851
|
| Memory | 4x DDR5 UDIMM, Maximum Memory Capacity 256GB Memory Support 9200 – 6400 (OC) MT/s / 6400 – 4800 (JEDEC) MT/s Max. overclocking frequency: • 1DPC 1R Max speed up to 9200+ MT/s • 1DPC 2R Max speed up to 7200+ MT/s • 2DPC 1R Max speed up to 6400+ MT/s • 2DPC 2R Max speed up to 5600+ MT/s Supports Intel® POR Speed and JEDEC Speed
|
| Onboard Graphics | 1x HDMI™ Support HDMI™ 2.1 with FRL, maximum resolution of 8K 60Hz*/ ** 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz*/ ** 1x Type-C DisplayPort Thunderbolt™ 4 ports, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz* |
| Slot | 2x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
|
| Audio | Realtek® ALC897 Codec 7.1-Channel High Definition Audio Supports S/PDIF output
|
| Storage | 3x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices 4x SATA 6G |
