MSI PRO B860M-A WIFI6E M-ATX MOTHERBOARD DDR5
Original price was: ₹22,099.00.₹16,479.00Current price is: ₹16,479.00.
- Next-Gen Intel Platform – Supports Intel Core Ultra Processors (Series 2) with the LGA 1851 socket.
- High-Speed DDR5 Memory – Supports up to 256GB DDR5 with speeds reaching 8800+ MT/s (OC).
- PCIe 5.0 Graphics Support – Provides high-bandwidth connectivity for modern graphics cards.
- Lightning Gen 5 Storage – Features a PCIe 5.0 x4 M.2 slot for ultra-fast NVMe SSD performance.
- Wi-Fi 6E Connectivity – Delivers fast and reliable wireless networking with support for the 6GHz band.
- 5G LAN – Realtek 5Gbps LAN provides high-speed wired connectivity for gaming, streaming and large file transfers.
- Compact Micro-ATX Design – The 243.84 × 243.84 mm form factor is ideal for compact yet powerful PC builds.
- Strong Power Delivery – 12+1+1+1 Duet Rail Power System with P-PAK provides a stable platform for high-performance processors.
Available on backorder
MSI PRO B860M-A WIFI6E M-ATX MOTHERBOARD DDR5
The MSI PRO B860M-A WIFI6E is a compact and powerful Micro-ATX motherboard designed for Intel Core Ultra Processors (Series 2). Featuring DDR5 memory support, PCIe 5.0, Lightning Gen 5 M.2 storage, Wi-Fi 6E, 5G LAN and a robust power design, it delivers a strong foundation for modern gaming, productivity and high-performance PC builds.
Key Features
- Intel B860 chipset with LGA 1851 socket
- Supports Intel Core Ultra Processors (Series 2)
- 4 × DDR5 DIMM slots with up to 256GB capacity
- DDR5 speeds up to 8800+ MT/s (OC)
- 12+1+1+1 Duet Rail Power System with P-PAK
- PCIe 5.0 x16 graphics slot
- 3 × M.2 slots, including PCIe 5.0 x4 support
- Wi-Fi 6E with up to 2.4Gbps wireless speed
- Realtek 5G LAN for high-speed wired networking
- USB 10Gbps Type-C connectivity
- 6-layer server-grade PCB
- Extended heatsink and M.2 Shield Frozr
- EZ PCIe Clip II and EZ Antenna
- Thunderbolt 5 card connector support
- 4 × EZ Debug LEDs
Specifications
| Specification | Details |
|---|---|
| Form Factor | Micro-ATX (mATX) |
| Dimensions | 243.84 × 243.84 mm |
| CPU Socket | LGA 1851 |
| Chipset | Intel B860 |
| CPU Support | Intel Core Ultra Processors (Series 2) |
| Memory Type | DDR5 |
| Memory Slots | 4 × DDR5 UDIMM |
| Maximum Memory | Up to 256GB |
| Memory Speed | Up to DDR5-8800+ MT/s (OC) |
| Primary PCIe Slot | PCIe 5.0 x16 |
| Additional PCIe Slots | PCIe 4.0 x1 + PCIe 4.0 x1 + PCIe 4.0 x4 |
| M.2 Slots | 3 × M.2 |
| M.2 Support | 1 × PCIe 5.0 x4 + 1 × PCIe 4.0 x4 + 1 × PCIe 4.0 x2 |
| SATA | 4 × SATA 6Gb/s |
| Wireless | Wi-Fi 6E |
| Wireless Speed | Up to 2.4Gbps |
| Bluetooth | Bluetooth 5.3 |
| LAN | Realtek 8126 5Gbps LAN |
| USB | USB 10Gbps Type-C + USB 10Gbps Type-A |
| Display Output | HDMI 2.1 + DisplayPort 1.4 |
| Audio | Realtek ALC897, 7.1-Channel HD Audio |
| Power Design | 12+1+1+1 Duet Rail Power System with P-PAK |
| PCB | 6-Layer Server-Grade PCB |
| Cooling | Extended Heatsink + M.2 Shield Frozr |
| Debug Feature | EZ Debug LED + EZ Memory Detection LED |
| Operating System | Windows 11 64-bit |
| Color | Silver |
