NOCTUA NF-A14 5V PWM – DC5V, 14025 Fan, 1500RPM
Original price was: ₹3,499.00.₹2,339.00Current price is: ₹2,339.00.
- Premium 5V 140mm PWM cooling fan for low-voltage systems
- Quiet operation with a maximum noise level of 24.6 dB(A)
- High airflow of 82.52 CFM for efficient cooling
- PWM-controlled speed from 0–1500 RPM
- Durable SSO2 bearing with MTTF exceeding 150,000 hours
- 20cm cable with 4-pin PWM connector for flexible installation
- Optimized aerodynamic blade design for superior airflow and low noise
- Ideal for embedded systems, Raspberry Pi projects, USB-powered cooling, and industrial electronics
Available on backorder
NOCTUA NF-A14 5V PWM – DC5V, 14025 Fan, 1500RPM
The Noctua NF-A14 5V PWM is a premium 140mm cooling fan designed for 5V-powered applications such as USB-powered devices, embedded systems, single-board computers, and other low-voltage electronics. Featuring Noctua’s renowned AAO (Advanced Acoustic Optimisation) frame, SSO2 bearing, and PWM speed control, it delivers excellent airflow, quiet operation, and outstanding reliability. The fan includes a 4-pin PWM connector, a 200mm (20cm) cable, and supports intelligent speed control up to 1500 RPM.
Key Features
- Premium 140 × 140 × 25mm cooling fan
- DC 5V operation for low-voltage applications
- 4-pin PWM interface with automatic speed control
- Maximum fan speed of 1500 RPM
- 200mm (20cm) cable for easy installation
- Advanced AAO frame with Flow Acceleration Channels for improved airflow
- Premium SSO2 bearing for quiet operation and extended lifespan
- Ideal for USB-powered devices, embedded systems, and DIY cooling projects
Specifications
| Specification | Details |
|---|---|
| Model | Noctua NF-A14 5V PWM |
| Fan Size | 140 × 140 × 25 mm |
| Rated Voltage | DC 5V |
| Connector | 4-pin PWM |
| Cable Length | 200 mm (20 cm) |
| Speed Range | 0–1500 RPM |
| Maximum Airflow | 140.2 m³/h (82.52 CFM) |
| Maximum Static Pressure | 2.08 mm H₂O |
| Maximum Noise Level | 24.6 dB(A) |
| Bearing Type | SSO2 Bearing |
| Motor Type | Single Phase |
| Warranty | 6 Years |
