| CPU |
Intel® Core™ i5-12400 6-core/12-thread Processor, burst up to 4.4 GHz |
| CPU Architecture |
64-bit x86 |
| Graphic Processors |
Intel® UHD Graphics 730 |
| Floating Point Unit |
YES |
| Encryption Engine |
(AES-NI) |
| Hardware-accelerated Transcoding |
YES |
| System Memory |
32 GB SODIMM DDR4 |
| Maximum Memory |
64 GB ( 2 x 32 GB) |
| Memory Slot |
2 x SODIMM DDR4 |
| Flash Memory |
5GB (Dual boot OS protection) |
| Drive Bay |
8 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility |
3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA solid state drives |
| Hot-swappable |
(Not supported M.2 SSD) |
| M.2 Slot |
2 x M.2 2280 PCIe Gen 4 x4 slots
Compatible with NVMe SSD PCIe Gen 3 and above
|
| SSD Cache Acceleration Support |
YES |
| GPU pass-through |
YES |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
2 (2.5G/1G/100M/10M) |
| 5 Gigabit Ethernet Port (5G/2.5G/1G/100M) |
Optional via PCIe expansion card |
| 10 Gigabit Ethernet Port |
Optional via PCIe expansion card |
| Wake on LAN (WOL) |
YES |
| Jumbo Frame |
YES |
| PCIe Slot |
2
Slot 1: PCIe Gen 4 x16
Slot 2: PCIe Gen 4 x4
Card dimensions for PCIe slot 1~Slot 2：185 x 131.15 x 18.76 mm / 7.28 x 5.16 x 0.74 inches.
Wider cards can be installed if the next PCIe slot will not be used.
|
| USB 3.2 Gen 2 (10Gbps) Port |
1 x Type-C USB 3.2 Gen 2 10Gbps
2 x Type-A USB 3.2 Gen 2 10Gbps |
| HDMI™ Output |
1, HDMI™ 1.4b (up to 4096 x 2160 @ 30Hz) |
| Form Factor |
Tower |
| LED Indicators |
HDD 1-8, Status, LAN, USB port, M.2 port |
| LCD Display/ Button |
YES |
| Buttons |
Power, Reset, USB Copy |
| Dimensions (HxWxD) |
188.2 × 329.3 × 280.8 mm
Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model)
|
| Weight (Net) |
7.3 kg |
| Weight (Gross) |
8.95 kg |
| Operating Temperature |
0 – 40 °C (32°F – 104°F) |
| Storage Temperature |
-20 – 70°C (-4°F – 158°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit |
250W, 100-240V |
| Power Consumption: Disk Standby Mode |
58.127 W |
| Power Consumption: Operating Mode, Typical |
81.865 W
Tested fully populated with WD10EFRX hard drives.
|
| Fan |
System fan: 2 x 120mm, 12VDC
CPU fan: 1 x 60mm, 12VDC |
| System Warning |
Buzzer |
| Kensington Security Slot |
YES |
| Standard Warranty |
3 |
| Max. Number of Concurrent Connections (CIFS) – with Max. Memory |
3500 |
