Leetop A618 Carrier Board
Original price was: ₹28,999.00.₹21,999.00Current price is: ₹21,999.00.
The Leetop A618 Carrier Board is an industrial-grade embedded AI carrier board designed for NVIDIA Jetson Orin Nano and Jetson Orin NX modules. Featuring DisplayPort, Gigabit Ethernet, 4 × USB 3.2, dual M.2 NVMe SSD slots, M.2 Wi-Fi/Bluetooth expansion, dual 4-Lane MIPI CSI-2 camera interfaces, CAN Bus, and industrial GPIO connectivity, it provides a powerful platform for robotics, machine vision, industrial automation, AI video analytics, and edge AI applications.
Leetop A618 Carrier Board
Features
- Supports Jetson Orin Nano and Jetson Orin NX modules.
- Delivers up to 157 TOPS AI performance (module dependent).
- 1 × DisplayPort supporting high-resolution displays.
- 1 × Gigabit Ethernet for industrial networking.
- 4 × USB 3.2 Type-A ports.
- 1 × USB Type-C supporting USB 3.2 and USB 2.0.
- 2 × M.2 Key M slots supporting 2230 and 2280 NVMe SSDs.
- 1 × M.2 Key E slot for Wi-Fi and Bluetooth modules.
- 2 × 4-Lane MIPI CSI-2 camera connectors for advanced AI vision.
- Industrial interfaces including CAN, SPI, I²C, UART, I²S, and GPIO.
- 9V–20V DC wide-range power input with 60W maximum load.
- Designed to meet industrial requirements including anti-static (ESD) and vibration resistance.
Specifications
| Product Name | Leetop A618 Carrier Board |
| Brand | Leetop |
| Product Type | Embedded AI Carrier Board |
| Compatible Modules | NVIDIA Jetson Orin Nano 4GB / 8GB, NVIDIA Jetson Orin NX 8GB / 16GB |
| Module Connector | 260-pin SO-DIMM |
| Supported AI Performance | Up to 157 TOPS (with Jetson Orin NX 16GB), 117 TOPS (Orin NX 8GB), 67 TOPS (Orin Nano 8GB), 34 TOPS (Orin Nano 4GB) |
| Display Output | 1 × DisplayPort (DP) |
| Ethernet | 1 × Gigabit Ethernet (10/100/1000 Mbps) |
| USB Ports | 4 × USB 3.2 Type-A, 1 × USB Type-C (USB 2.0 + USB 3.2) |
| Storage Expansion | 2 × M.2 Key M (2230 / 2280 NVMe SSD) |
| Wireless Expansion | 1 × M.2 Key E (Wi-Fi / Bluetooth) |
| Camera Support | 2 × 4-Lane MIPI CSI-2 Camera Connectors |
| CAN Bus | 1 × CAN Interface |
| RTC | 1 × 3V RTC Connector |
| Fan Header | 1 × 5V PWM Fan Connector |
| Expansion Interfaces | 2 × SPI, 2 × I²C, 2 × UART, 1 × I²S, 6 × GPIO |
| Power Input | 9V–20V DC (Max 60W) |
| Recommended Power Supply | 60W or Higher |
| Dimensions | 100 × 79 mm |
| Operating Temperature | -25°C to +65°C |
| Storage Environment | -25°C to +65°C, 10%–90% RH (Non-Condensing) |
