MSI MAG B760M MORTAR WIFI II DDR5 M-ATX MOTHERBOARD

The MSI MAG B760M MORTAR WIFI II is a powerful Micro-ATX gaming motherboard designed for Intel Core 14th, 13th, and 12th Gen processors using the LGA 1700 socket. It supports high-speed DDR5 memory up to 7800+ MT/s (OC), PCIe 5.0, three PCIe 4.0 M.2 slots, 2.5G LAN, Wi-Fi 6E, Bluetooth 5.3, and USB 20Gbps connectivity. With a 12+1+1 Duet Rail Power System, extended heatsinks, M.2 Shield Frozr, and a 6-layer 2oz copper PCB, it provides a strong platform for gaming and high-performance PC builds.

Key Features

• Intel B760 chipset with LGA 1700 socket
• Supports Intel Core 14th, 13th and 12th Gen processors
• Micro-ATX form factor
• 4 x DDR5 DIMM slots
• Supports up to 256GB DDR5 memory
• DDR5 speeds up to 7800+ MT/s (OC)
• Intel XMP support
• 1 x PCIe 5.0 x16 slot
• 1 x PCIe 3.0 x4 slot
• 3 x M.2 slots
• All M.2 slots support PCIe 4.0 x4
• Third M.2 slot also supports SATA mode
• 4 x SATA 6Gb/s ports
• Realtek 2.5Gbps LAN
• Intel Wi-Fi 6E
• Bluetooth 5.3
• Rear USB 20Gbps Type-C
• Front USB 10Gbps Type-C
• HDMI 2.1 and DisplayPort 1.4
• Realtek ALC897 7.1-channel HD Audio
• S/PDIF output
• 12+1+1 Duet Rail Power System
• Dual 8-pin CPU power connectors
• Extended heatsink design
• M.2 Shield Frozr
• 6-layer PCB with 2oz thickened copper
• 4 x EZ Debug LEDs
• Windows 11 and Windows 10 64-bit support

                                        Specifications
