Netgear M4250-16XF 16x1G/10G Fiber SFP+ Managed Switch
Original price was: ₹699,999.00.₹499,999.00Current price is: ₹499,999.00.
The Netgear AV Line M4250-16XF is a high-performance 16‑port fiber switch with 16×1G/10G SFP+ ports, ideal for full-fiber network deployments. It supports advanced Layer 2/Layer 3 switching, VLANs, QoS, IGMP Plus™ multicast, and AVB for AV over IP or enterprise backbone networks.
Netgear M4250-16XF 16x1G/10G Fiber SFP+ Managed Switch
Features
- 16 × SFP/SFP+ fiber ports supporting 1G and 10G speeds for full‑fiber connectivity.
- Fully managed Layer 2/Layer 3 switching with VLANs, QoS, ACLs, static routing, and advanced traffic control.
- High‑speed uplinks capable of 10 Gbps per SFP+ port for backbone and long‑distance links.
- 96 Gbps non‑blocking switching fabric for robust throughput across all fiber ports.
- Enhanced NETGEAR IGMP Plus™ multicast support optimized for AV over IP and other multicast traffic.
- Jumbo frame support (up to 12 KB) for efficient large‑packet transmission.
- Multiple management interfaces such as Web GUI, SNMP, SSH/CLI, and console for configuration and monitoring.
- Rack‑mountable design with selectable fan modes (quiet/cool) for flexible deployment in professional network environments.
Specifications
| Model | M4250‑16XF (XSM4216F) |
| Total Ports | 16 × SFP/SFP+ fibre ports |
| Port Speeds | Supports 1G and 10G per SFP/SFP+ slot |
| PoE Support | None (no PoE/PoE+ ports) |
| Primary Port Speed | 1 Gigabit base speed (per module) |
| Switching Fabric | Fibre ASIC non‑blocking architecture (per port fibre design) |
| IGMP Support | Enhanced NETGEAR IGMP Plus™ multicast |
| Jumbo Frame Support | Yes — up to 12 KB frames |
| AVB Support | Yes (license required) |
| Management Interfaces | Web GUI, CLI (SSH/Telnet), SNMP, Console (USB‑C & RJ45) |
| Dimensions (W×D×H) | 440 × 200 × 43.2 mm |
| Weight | ~2.8 kg |
| Operating Noise | Fanless or ~56.7 dB @ 25 °C |
| Power Consumption | ~47.8 W full load / ~19.3 W idle |
| Rack Mountable | Yes — standard 1U mounting brackets included |
