Netgear M4300-12X12F XSM4324S Fully Managed switch
Original price was: ₹699,999.00.₹599,999.00Current price is: ₹599,999.00.
The Netgear M4300-12X12F is a fully managed Layer 3 switch with 24× 10Gb ports (12× RJ45 and 12× SFP+) for high-speed enterprise networking.
It delivers 480Gbps non-blocking performance with advanced L2/L3 routing, VLAN, multicast, and strong security features.
Designed with a half-width 1U form factor, it supports stackable architecture for scalable, reliable core and aggregation deployments.
Netgear M4300-12X12F XSM4324S Fully Managed switch
Features
- 24 × 10 Gb Ports (12× RJ45 + 12× SFP+) – All 24 ports support 10G speeds and are backward compatible with 1 G/100 M.
- 480 Gbps Non-Blocking Switching Fabric – High throughput for demanding core or aggregation network traffic.
- Layer 2/Layer 3/Layer 4 Features Without License – Advanced routing (static, RIP, OSPF, VRRP, PIM), policy-based routing, ACLs for flexible traffic control.
- Stackable Architecture with NSF – Stack multiple units with nonstop forwarding and hitless failover for high availability.
- Flexible Half-Width Form Factor – Two switches can fit in a single 1U space for redundant Top-of-Rack deployment.
- Comprehensive Management Options – Out-of-band Ethernet port, RS-232 and Mini-USB console ports, USB storage, SNMP, CLI, Web GUI, SSH, RSPAN.
- Multicast & AV-Over-IP Ready – Pre-configured for Layer 2 multicast and SDVoE/AV-over-IP applications.
- Advanced Security & High Resiliency – Features like DHCP Snooping, IP Source Guard, DoS protection, PVSTP/PVRSTP support, and distributed link aggregation.
Specifications
| Model | M4300-12X12F (XSM4324S) |
| Switch Type | Fully Managed Layer 3 Stackable Switch |
| 10GBASE-T RJ45 Ports | 12 × 10GBASE-T (100M/1G/10G) |
| 10G SFP+ Fiber Ports | 12 × SFP+ (1G/10G) |
| Total 10G Ports | 24 independent 10G ports |
| Switching Fabric | 480 Gbps non-blocking |
| Forwarding Rate | ~357 Mpps |
| Management Ports | 1 × Out-of-band 1G Ethernet, RJ45 RS-232 console, Mini-USB console, USB storage |
| Layer Support | Layer 2 / Layer 3 / Layer 4 with policy-based routing, RIP, OSPF, VRRP, PIM |
| Stacking | Virtual chassis stacking with nonstop forwarding (NSF) and hitless failover |
| VLAN Support | Up to 4093 VLANs |
| Jumbo Frames | Supported (up to ~9 KB) |
| Power Supply | 1 × APS250W modular PSU included |
| Power Consumption (Max) | ~97 W |
| Acoustics | ~36.9 dB @ 25 °C |
| Form Factor | 1U Half-Width (two units can fit in one rack space) |
| Packet Buffer Memory | ~32 Mb |
| MAC / ARP / Routes | ~128K MAC, 8K ARP/NDP, IPv4/IPv6 routing tables (varied per model) |
| Firmware & Management | Web GUI, CLI (SSH/Telnet), SNMP, NMS300 support |
