Netgear XS512EM 12 Port Non-Poe Smart Managed Gigabit Switch
₹299,999.00
The Netgear XS512EM is a 12-port Multi-Gig smart managed switch designed for high-performance business networks, supporting speeds from 100 Mbps up to 10 Gbps on all RJ-45 ports along with two shared SFP+ uplink ports.
Netgear XS512EM 12 Port Non-Poe Smart Managed Gigabit Switch
Features
- 12 Multi-Gigabit RJ45 Ports – Auto-negotiate at 100 M / 1 G / 2.5 G / 5 G / 10 G speeds.
- 2 Shared SFP+ Ports – Support 10 Gb fiber or DAC uplinks.
- Smart Managed – Web GUI for configuration and monitoring.
- VLAN Support – Network segmentation for security and performance.
- QoS (Quality of Service) – Prioritize voice/video and critical traffic.
- Link Aggregation (LAG/LACP) – Combine ports for higher throughput or redundancy.
- IGMP Snooping & Loop Prevention – Better multicast handling and network stability.
- High Switching Capacity – ~240 Gbps with jumbo frame support for heavy traffic.
Specifications
| Model | XS512EM 12 Port Non-Poe |
| Management Type | Smart Managed (web GUI) |
| Total Ports | 12 × RJ-45 Multi-Gig Ports + 2 × Shared SFP+ |
| Port Speeds Supported | 100 M, 1 G, 2.5 G, 5 G, 10 G on RJ-45 |
| SFP+ Ports | 2 (shared with copper) |
| Switching Bandwidth | 240 Gbps |
| Packet Buffer Memory | 3 MB |
| MAC Address Table | 32 K entries |
| VLAN Support | Yes (up to 64 VLANs) |
| Link Aggregation (LAG) | Yes (up to 8 LAGs) |
| Multicast Groups | 128 |
| Jumbo Frames Support | Up to ~9000 bytes |
| IGMP Snooping / Multicast | Yes |
| QoS / Priority Queues | Yes |
| Energy Efficient Ethernet | IEEE 802.3az |
| Form Factor | Rackmount / Desktop |
| Dimensions (W×D×H) | 328 × 204 × 43 mm |
| Weight | 2.51 kg |
| Fans | 2 × Active |
| Power Consumption (max) | ~76.56 W |
| LED Indicators | Power, Speed, Link/Activity, Fan |
| Operating Temperature | 0 °C – 50 °C |
