NetgearM4300-24X XSM4324CS Fully Managed switch
Original price was: ₹799,999.00.₹599,999.00Current price is: ₹599,999.00.
The Netgear M4300-24X (XSM4324CS) is a fully managed Layer 3 switch with 24× 10GBASE‑T ports and 4× SFP+ fiber uplinks for high-speed enterprise connectivity.
It delivers 480 Gbps non-blocking performance with advanced L2/L3/L4 features, VLANs, QoS, and stackable architecture for scalable networks.
Designed as a half-width 1U rack switch, it offers high availability, multicast/AV-over-IP support, and robust security for mission-critical deployments.
NetgearM4300-24X XSM4324CS Fully Managed switch
Features
- 24× 10GBASE‑T Ports + 4× Shared SFP+ – High‑speed copper 10GbE connectivity with additional fiber uplink flexibility.
- Fully Managed Layer 2/Layer 3/Layer 4 – Advanced switching, routing, and policy features with no extra license needed.
- Stackable with Virtual Chassis – Stack multiple units and manage as one logical switch with nonstop forwarding (NSF).
- High Availability & Multi‑Resiliency – Hitless failover, distributed link aggregation, and PVST+/PVRSTP support for reliable networks.
- Advanced Security – Malicious code detection, DHCP Snooping, IP Source Guard and DoS protection.
- Non‑Blocking High Performance – Up to ~960 Gbps switch fabric and ~714 Mpps forwarding rate for demanding traffic.
- AV‑Over‑IP & Multicast Ready – Pre‑configured L2 multicast and SDVoE support for media/AV networks.
- Efficient Management & GUI – Web GUI, CLI, SNMP, sFlow, RSPAN, and single‑pane‑of‑glass NMS300 support.
Specifications
| Model | XSM4324CS (M4300‑24X) |
| Switch Type | Fully Managed Layer 2 / Layer 3 / Layer 4 |
| 10GBASE‑T RJ45 Ports | 24 × 10GBASE‑T (100M / 1G / 10G) |
| SFP+ Fiber Ports | 4 × SFP+ (1G / 10G), shared configuration |
| Switching Fabric | 480 Gbps non‑blocking |
| Forwarding Rate | Up to ~714 Mpps |
| MAC/ARP/NDP Table Size | 128 K MAC, 8 K ARP/NDP |
| IP Multicast | 1,024 IPv4 / 512 IPv6 entries |
| Multicast IGMP Membership | 2 K IPv4 / IPv6 |
| Routing Protocol Support | Static, RIP, OSPF, VRRP, PIM |
| VLAN Support | 4093 VLANs, DHCP pools (IPv4/IPv6) |
| Management Ports | 1 × out‑of‑band 1G Ethernet, RJ45 RS‑232 console, Mini‑USB console, USB storage |
| Stacking Features | Mix‑and‑match stackable with nonstop forwarding and failover |
| Power Supply | 1 × modular APS250W PSU included |
| Cooling / Noise Level | Fixed front‑to‑back fan, ~37 dB |
| Latency | <0.9 µs (10G SFP+), <1.25 µs (10G RJ45) |
| Form Factor | Half‑width 1U rack mount (can install two side‑by‑side) |
| Security & QoS Features | Advanced IPv4/IPv6 security, QoS, access controls |
