Tanna TechBiz Eagle 201-Embedded AI System with Nvidia Jetson Orin Nx 16GB Module
Original price was: ₹249,999.00.₹158,999.00Current price is: ₹158,999.00.
Buy the Tanna TechBiz Eagle 201 Embedded AI System (SYS-TTB-0007) with NVIDIA Jetson Orin NX 16GB, featuring 157 AI TOPS, 1024 CUDA Cores, 32 Tensor Cores, 8-core Arm Cortex-A78AE CPU, 16GB LPDDR5 memory, M.2 NVMe SSD support, Gigabit Ethernet, USB 3.0, DisplayPort, dual MIPI CSI camera connectors, and JetPack SDK support. Ideal for robotics, AI video analytics, machine vision, industrial automation, autonomous mobile robots, and edge AI solutions.
Available on backorder
Tanna TechBiz Eagle 201-Embedded AI System with Nvidia Jetson Orin Nx 16GB Module
Features
- NVIDIA Jetson Orin NX 16GB with Super Mode support.
- Up to 157 AI TOPS for advanced edge AI inference.
- 1024 CUDA Cores and 32 Tensor Cores based on NVIDIA Ampere architecture.
- 8-Core Arm Cortex-A78AE CPU running at 2.0 GHz.
- 16GB LPDDR5 memory with 102 GB/s bandwidth.
- Supports 2280 NVMe SSD through M.2 Key M.
- Dual MIPI CSI camera interfaces for AI vision applications.
- Rich I/O including USB 3.0, USB Type-C, Gigabit Ethernet, DisplayPort, CAN, GPIO, SPI, I²C, and UART.
- Compatible with JetPack SDK, CUDA, TensorRT, DeepStream, Isaac ROS, PyTorch, and TensorFlow.
Specifications
| Product Name | Tanna TechBiz Eagle 201 Embedded AI System |
| Brand | Tanna TechBiz |
| AI Module | NVIDIA Jetson Orin NX 16GB (Super Mode Supported) |
| Product Type | Embedded AI Edge Computing System |
| AI Performance | Up to 157 TOPS (Sparse) / 78 TOPS (Dense) |
| GPU | NVIDIA Ampere GPU |
| CUDA Cores | 1024 CUDA Cores |
| Tensor Cores | 32 Tensor Cores |
| GPU Frequency | 1020 MHz |
| CPU | 8-Core Arm Cortex-A78AE @ 2.0 GHz |
| DLA Performance | 80 TOPS (Sparse) / 40 TOPS (Dense) |
| Memory | 16GB LPDDR5 |
| Memory Bandwidth | 102 GB/s |
| Module Power Modes | 10W / 15W / 25W / 40W (MAXN SUPER) |
| Storage | 1 × M.2 Key M (Supports 2280 NVMe SSD) |
| Ethernet | 1 × RJ-45 Gigabit Ethernet (10/100/1000 Mbps) |
| Wireless Expansion | 1 × M.2 Key E (Supports Wi-Fi/Bluetooth Module – RTL8822CE) |
| USB Ports | 4 × USB 3.0 Type-A, 1 × USB Type-C (Data Only) |
| Camera Interfaces | 2 × MIPI CSI 2-Lane 22-Pin Connectors |
| Display Output | 1 × DisplayPort |
| Cooling | Heatsink Ready (Fan Connector Available) |
| Fan Header | 1 × 4-Pin PWM Fan Connector (5V) |
| Expansion | 40-Pin GPIO Header, 12-Pin Button Header, GPIO, I²C, I²S, SPI, UART |
| CAN Bus | 1 × CAN Interface |
| RTC | 1 × RTC Connector (Supports CR1220 Battery – Not Included) |
| Power Input | DC 9V–19V, 4.74A Max |
| Dimensions | 40 × 80 × 38 mm |
| Operating Temperature | 0°C to 45°C |
| Operating System | NVIDIA JetPack SDK (Ubuntu Linux) |
| AI Frameworks | CUDA, TensorRT, cuDNN, DeepStream, Isaac ROS, OpenCV, PyTorch, TensorFlow |
| Warranty | 3 Years |
